Save Water Safe Water
Characteristics
Material of Construction – Motor
- Oil Seal: Nitrile butyl rubber
- Motor Shaft: SS-420
- Motor Body Pipe: SS-304
- Motor Bush: LTB-4
- Thrust bearing assembly: SS – 420
- Diaphragm: High Nitrile Butyl Rubber
- Housing Set: Cast Iron
Material of Construction – Pump
- Check Valve Housing: Cast iron
- Outer Shell: SS-304
- Impeller: Noryl
- Bowl: Noryl
- Counter Bush: LTB-4
- Pump Bush : NBR / LTB 4
- Pump Sleeve: SS-410
- Suction: Cast iron
- Pump Shaft: SS-410
- Coupling / Pump Couple: SS-410
Salient Features
- Motor portion covered with corrosive resistance Stainless steel SS-304
- More durability and hygiene
- High operating efficiency
- Specially designed thrust bearing to withstand high axial thrust load
- Extremely hardwearing water lubricated bearing
- Thread type motor construction ensures service feasibility
- Specially designed Deep Drawn type pump ensures perfect alignment and thereby increases the life of the pump set
- Designed for wide voltage operation
- Best alternative for JET & Compressor pump set
- Additional intermediate bearing in higher stage pumps.
